STR 12V 0.8kW 8T, HYUNDAI GETZ AUTO TRANS, G4EC, G4ED ENGINE
Voltage12VKilowatt0.8kWNumber of Teeth8TPinion Diameter28mmRotationCWPinion at Rest10mmFlange Diameter77mmMount Hole Center to Center105mmMount Hole DiameterM10Overall Length190mmOil SealedSeriesGroundNEGATIVEHousing IndexFIXEDWeight (Kg)4.0kg
Category: Starter Motor
| Voltage | 12V |
| Kilowatt | 0.8kW |
| Number of Teeth | 8T |
| Pinion Diameter | 28mm |
| Rotation | CW |
| Pinion at Rest | 10mm |
| Flange Diameter | 77mm |
| Mount Hole Center to Center | 105mm |
| Mount Hole Diameter | M10 |
| Overall Length | 190mm |
| Oil Sealed | |
| Series | |
| Ground | NEGATIVE |
| Housing Index | FIXED |
| Weight (Kg) | 4.0kg |
