Description

• LiFePO4 Chemistry
• Group 8D Size (20.9″ x 8.7″ x 12.1″) L x W x H
• 100Ah Capacity
• 150A Max Continuous Discharge (300A 30s Discharge)
• 150A Max Continuous Charge (300A 10s Charge)
• IP67 Rated, Dust and WATERPROOF
• HEATED – Internal heating for below 0C charging
• BLUETOOTH – iOS and Android Apps
• CANBUS Communication allows BMS to communicate directly with Victron OS
• Mountable ON/OFF Switch
• Mountable Battery gauge
• Built-in Smart Battery Management System (BMS)
• Internal fuse with current and temperature protections
• Over charge and over discharge protection
• Over current and short circuit protection
• High & low temperature disconnects
• 3500+ Cycle life & Maintenance-free
• 11 Year Manufacturer Warranty

Weights and Dimensions

Weight: 97lbsDimensionsLength:20.75(inches)Width:8.5(inches)Height:12(inches)
Specs
ConfigurationCell Configuration:16S1PChemistry:LiFePO4CurrentAh Capacity:100AhMax Continuous Discharge Amps:150AMax Charge Current Amps:150AMax Discharge Peak Current Amps:300A @ 30secSeries | Parallel:Max (16) in Parallel, Plug & PlayVoltageVoltage:51.2VMax Charge Voltage:58.4VOperating Voltage Range:48.0V – 58.4VTemperatureCharge Temp Range:-30C (-22F) / 55C (131F) (with heating)Discharge Temp Range:-20C (-4F) / 55C (131F)Storage Temp:-20C (-4F) / 45C (113F)
